Model | i-Standard Series | ||||
---|---|---|---|---|---|
i-Standard 04 | x | x | |||
Video | Camera input | 4 POE | x | x | |
IP Camera | Spec | ONVIF 1812, RTSP, H.264, H.265, dual stream | |||
Resolution | upto 8M | ||||
Num | 4 | x | x | ||
Output | 1 HDMI (Main Display or Programmable HD Spot) 1 VGA (Main Display or Programmable HD Spot) |
||||
Audio | Audio input | 1 RCA | |||
Output | 1 RCA | ||||
Sensor In | 4 (NC, NO selectable) | x | x | ||
Alarm out | 1 relay | x | |||
Operating System | Embedded Linux OS | ||||
Display | Speed | Real Time | |||
Resolution (Pixel) | 1280X1024, 1280X720, 1920X1080, 3840x2160(UHD) | ||||
Split screen | 1,4 | x | x | ||
Main IPC |
CODEC | H.264, H.265 | |||
Resolution (Pixel) / fps | main: upto 8MP @ 30 sub: upto 960x540 |
||||
Total Bitrate | 200Mbps | ||||
Channel Bitrate | 50 Mbps | x | x | ||
Playback | Display | 1,4 | x | x | |
Search mode | Calendar, Event ,POS , Panorama, Thumbnail, Bookmark | ||||
Fast/Slow speed | Normal, REW & FF [recorded speed 2x, 4x, 8x, 16x, 32x, 64x, 1/2x , 1/4x], Frame to frame, Pause | ||||
Network | Network Interface | Gigabit Ethernet | |||
Application | Windows 7 / 8 / 10 (PC Client system& IE)/MAC | ||||
Web Browser | Internet Explorer, Safari | ||||
Smart phone App | Android, iPhone for live and search | ||||
Backup | Backup device | External HDD and CD/DVD-RW, Network, Thumb Drive | |||
The number of HDD | 2 SATA + 1 eSATA(upto 12 bays, No capacity limit ; 10TB or more) | ||||
Function | · Full GUI with alpha blending | ||||
· Individual setting of resolution, frame rates and picture quality | |||||
· Instant Replay | |||||
· Digital Zoom | |||||
· Mouse Control | |||||
· Weekly scheduler with holiday by 10 minutes setting | |||||
· Covert, Disable and Private function of cameras | |||||
· Motion Detection with 576 area setting | |||||
· Relay alarm output | |||||
· PTZ control by RS-485 | |||||
· Daylight Saving Time and Network Time Setting | |||||
· Multi User Authority | |||||
· Deinterlacer upon live and playback | |||||
· Multi languages with full graphic | |||||
· Individual Network port setting | |||||
· Auto Deletion | |||||
· Import and Export the configuration | |||||
· Interactive setup via network | |||||
· POS Interface | |||||
· Mirroring | |||||
Others | Power Consumption | 57.6W (48V) | x | x | |
Operating Temperature | 0~40°C(32~104°F) | ||||
Relative Humidity | Maximum 80% non-condensing | ||||
Dimension | 380(W)×340(D)×50(H) mm |
